How Shengyi Tg150 ℃ S1000H Material Enhances the Performance of Multilayer PCBs

At the core of modern electronics lies a vital component - printed circuit boards (PCBs). With the increasing demands for high-performance electronics, the need for high-quality PCBs has become more critical than ever. Our newly shipped multilayer Shengyi Tg150 ℃ S1000H material and processed using lead-free techniques, this PCB is built to last.This S1000H PCB is designed to meet these demands and exceed expectations. In this comprehensive guide, we will take a deep dive into our S1000H PCB, its specifications, properties, and benefits.

Craftsmanship and Reliability: The Top Priorities inShengyi Tg150 ℃ S1000H PCBs

Our Shengyi Tg150 ℃ S1000H multilayer PCB is meticulously crafted with robustness and reliability as the top priority.Thelead-free process ensures optimized performance and longevity. With blind vias from layer 1 to layer 4, a finished thickness of 1.6mm, and a finished copper weight of 1.0 oz (1.4 mils) on all layers,The Shengyi Tg150 ℃ S1000H PCB can withstand the rigors of everyday use. Additionally,It can operate in temperatures ranging from -40℃ to +85℃, making it suitable for a wide range of applications.

Optimizing Signal Integrity: Impedance Matching inShengyi Tg150 ℃ S1000H PCBs

Impedance matching is crucial in any multilayer PCB, and ourShengyi Tg150 ℃ S1000H PCB is designed to meet the highest standards. With single-end impedance on the outlayer, 16mil, 14mil, and 7mil trace lines, our PCB can ensure optimal signal integrity for your electronics.

Surface Finish: Electroless Nickel and Immersion Gold (ENIG)

The Tg150 ℃ S1000H multilayer PCB is finished with electroless nickel and immersion gold (ENIG) surface finish, providing excellent solderability and corrosion resistance. Furthermore, our PCB undergoes a 100% electrical test, ensuring optimal functionality.

Technical Expertise: The Core ofTg150 ℃ S1000H Multilayer PCBs

At the core ofthe Tg150 ℃ S1000H multilayer PCBs is our technical expertise. Jane, our technical expert, oversees the creation of each PCB with unmatched attention to detail. With her expertise, we ensure that every multilayer S1000H PCB we create is of the highest quality.

Thermal, Mechanical, and Environmental Properties of Tg150 ℃ S1000H PCB

The multilayerTg150 ℃ S1000H PCB boasts impressive thermal, mechanical, and environmental properties. With a Tg of 155℃, a thermal stress of 288℃, and a CTI rating of PLC 3,It can withstand even the most demanding environments. The PCB also has a low water absorption rate of 0.09%, ensuring that it maintains its properties in humid conditions.

Tg and Td: Understanding the Thermal Properties ofTg150 ℃ S1000H

The Tg and Td ofthe S1000H Material multilayer PCB are crucial in determining its thermal properties. The Tg value indicates the temperature at which the PCB material changes from a glassy state to a rubbery state.ThePCB has a Tg value of 155℃, ensuring that it can withstand high temperatures without losing its structural integrity. The Td value indicates the temperature at which the PCB material starts to decompose.The S1000H Material has a Td value of 348℃, ensuring that it can withstand high temperatures without decomposition.

CTE and CRI: The Mechanical Properties ofTg150 ℃ S1000H PCB

The CTE (coefficient of thermal expansion) and CRI (creep resistance index) ofS1000H PCB are critical in determining its mechanical properties. The CTE value indicates the amount of expansion or contraction that occurs with temperature changes.The S1000H PCB has a CTE value of 37 ppm/℃ before Tg and 230 ppm/℃ after Tg. The CRI value indicates the resistance of the PCB to deformation under load.TheS1000H PCB has a CRI value of 2.8% at 50-260℃, ensuring its mechanical stability even under heavy loads.

CTI and Flammability: The Environmental Properties ofTg150 ℃ S1000H PCB

The CTI (comparative tracking index) and flammability rating ofS1000H PCB are critical in determining its environmental properties. The CTI value indicates the electrical insulation properties of the S1000H PCB material. S1000H PCB has a CTI rating of PLC 3, ensuring its electrical insulation properties. The flammability rating indicates the resistance of the PCB material to catch fire or propagate flames.It has a flammability rating of V-0, ensuring its safety in high-temperature environments.

In conclusion, our high-quality multilayer S1000H PCB with Shengyi Tg150 ℃ and lead-free process is a reliable choice for optimizing the performance of your electronics. With our technical expertise and attention to detail, you can be confident that our S1000H PCBs are of the highest quality.The S1000H PCB boasts impressive thermal, mechanical, and environmental properties, making it suitable for a wide range of applications. From its craftsmanship and reliability to its impedance matching and surface finish,this S1000H PCB is designed to exceed your expectations.

For any technical questions, please don't hesitate to get in touch with Jane at sales20@bichengpcb.com. With this high-quality S1000H PCB, you can be confident that your electronics will function at their best.
