RO3010 Mini PCB 5mil: A Revolutionary Solution for High-Frequency Applications

  • December 20. 2023
In the fast-paced world of electronics, innovation is key. As technology continues to advance at an unprecedented rate, the demand for high-performance printed circuit boards (PCBs) is on the rise. Enter the RO3010 Mini PCB 5mil 2-layer, a newly shipped PCB that promises to revolutionize the industry with its exceptional characteristics and unmatched performance. In this blog post, we will delve deep into the features, benefits, and applications of this cutting-edge PCB.


PCB Substrates: Unleashing the Power of Rogers RO3010 Ceramic-Filled PTFE Composites

At the heart of the RO3010 Mini PCB 5mil lies the Rogers RO3010 ceramic-filled PTFE composites. These innovative substrates exhibit a dielectric constant of 10.2+/- .30 at 10 GHz/23°C, ensuring superior signal integrity and reliable performance. With a dissipation factor of 0.0022 at 10 GHz/23°C, these substrates minimize signal loss and enable efficient transmission. The impressive thermal conductivity of 0.95 W/mK ensures effective heat dissipation, making the PCB suitable for high-power applications. Additionally, with a moisture absorption rate of just 0.05%, the RO3010 Mini PCB can withstand harsh environmental conditions, offering long-lasting reliability. Operating within a temperature range of -40℃ to +85℃, this PCB is versatile and adaptable to various applications.


Features & Benefits: Unparalleled Performance and Cost-Effectiveness

The Rogers 3010 Mini PCB boasts a multitude of features and benefits that set it apart from its counterparts in the market. Its low coefficient of thermal expansion (CTE) of 13 ppm/°C(X), 11 ppm/°C(Y), and 16 ppm/°C(Z) respectively ensure exceptional dimensional stability, even in extreme temperature conditions ranging from -55 to 288 °C. The CTE match to copper ensures reliable performance and prevents issues such as delamination and solder joint failure. Moreover, this PCB offers an economical laminate pricing for volume manufacturing processes, making it an ideal choice for cost-conscious manufacturers. The RO3010 Mini PCB is also suitable for use with multi-layer board designs, allowing for increased complexity and functionality.


Stackup: Unveiling the Architecture of the RO3010 Mini PCB 5mil

The RO3010 Mini PCB features a 2-layer rigid PCB stackup, carefully crafted to deliver optimal performance. The stackup consists of a copper layer of 35 μm, by the Rogers RO3010 substrate of 5mil (0.127mm), and another copper layer of 35 μm. This construction ensures excellent signal integrity, efficient power distribution, and enhanced durability.


Rogers 3010 substrate


Construction Details: Precision and Reliability at Every Step

When it comes to construction details, the RO3010 Mini 0.127mm laminate leaves no stone unturned. With a board dimension of 8mm x 8mm, this PCB is compact yet powerful. The minimum trace/space of 7/7 mils enables high-density designs, allowing for intricate circuitry. The minimum hole size of 0.20mm ensures precise drilling and accurate component placement. Moreover, the absence of blind vias simplifies the manufacturing process and reduces costs. With a finished board thickness of 0.2mm and a finished copper weight of 1 oz (1.4 mils) on outer layers, the RO3010 Mini PCB 5mil strikes the perfect balance between thickness and durability. The Via plating thickness of 20 μm guarantees reliable electrical connections and efficient signal transmission. The surface finish of bare copper adds an extra layer of protection and ensures optimal conductivity. Furthermore, the absence of top and bottom silkscreen and solder mask eliminates the risk of errors and simplifies the manufacturing process. To ensure the highest quality standards, every RO3010 Mini PCB undergoes a 100% electrical test prior to shipment, guaranteeing flawless performance.


PCB Statistics: Unleashing the Power of Simplicity

The Rogers RO3010 Mini PCB boasts remarkable PCB statistics that highlight its simplicity and efficiency. With only one component and three total pads, this PCB offers a streamlined design that simplifies assembly and reduces costs. The two thru-hole pads and one top SMT pad cater to a wide range of component types and ensure versatility. With two vias and one net, the RO3010 Mini5mil substratePCB optimizes signal routing and minimizes signal distortion.


Type of Artwork Supplied: Seamless Integration into Existing Workflows

To seamlessly integrate the RO3010 Mini PCB into existing manufacturing processes, the PCB is supplied with Gerber RS-274-X artwork. This industry-standard format ensures compatibility across a wide range of design software and allows for easy integration and manufacturing.


Accepted Standard: Meeting and Exceeding Industry Standards

The RO3010 Mini PCB 5mil meets and exceeds the IPC-Class-2 standard, guaranteeing top-notch quality and reliability. This acceptance standard ensures that the PCB adheres to rigorous manufacturing and performance criteria, making it a trusted choice for mission-critical applications.


Availability: A Global Solution

The RO3010 Mini PCB is available worldwide, making it accessible to manufacturers and designers across the globe. With its widespread availability, this PCB opens up new possibilities and empowers engineers to bring their innovative ideas to life.



Some Typical Applications: Unleashing the Full Potential of the RO3010 Mini PCB 5mil

The versatility of the RO3010 Mini PCB extends to a wide range of applications. Some typical areas where this PCB excels include:


a. Automotive radar applications: The RO3010 Mini PCB offers exceptional performance in automotive radar systems, ensuring reliable signal transmission and accurate object detection.


b. Global positioning satellite antennas: With its superior dielectric properties and remarkable stability, this PCB enables precise positioning and efficient satellite communication.


c. Cellular telecommunications systems - power amplifiers and antennas: The RO3010 Mini board empowers cellular telecommunication systems with its excellent signal integrity and efficient power distribution. It ensures seamless communication and reliable coverage.


d. Patch antenna for wireless communications: This PCB's compact size and exceptional performance make it an ideal choice for patch antenna applications. It enables robust and efficient wireless communication, ensuring reliable connectivity.


e. Direct broadcast satellites: The RO3010 Mini PCB facilitates the transmission and reception of signals in direct broadcast satellite systems, ensuring exceptional performance and reliable data transfer.


f. Datalink on cable systems: With its optimal signal integrity and reliable performance, this PCB is well-suited for datalink applications in cable systems, ensuring efficient data transfer and seamless connectivity.


g. Remote meter readers: RO3010 Mini 5mil PCB enables accurate and reliable remote meter reading, allowing for efficient monitoring and management of utilities.


h. Power backplanes: With its exceptional thermal conductivity and superior dimensional stability, this PCB is the ideal choice for power backplanes, ensuring efficient power distribution and minimizing power loss.



Contact Info: Expert Assistance at Your Fingertips

For any technical questions or inquiries regarding the RO3010 Mini PCB, please do not hesitate to contact our expert team at sales20@bichengpcb.com. Our skilled professionals are dedicated to providing exceptional customer service and technical support, ensuring a seamless experience from inquiry to delivery.


In conclusion, the RO3010 Mini 5mil high frequency PCB is a game-changing solution for high-frequency applications. With its exceptional characteristics, unmatched performance, and widespread availability, this PCB empowers engineers and designers to push the boundaries of innovation. Whether in automotive radar systems, satellite communication, or power backplanes, the Rogers 3010 Mini PCB ensures optimal performance, reliability, and longevity. Experience the future of PCB technology with the RO3010 Mini PCB 5mil and unlock endless possibilities in the world of electronics.
