Rogers TMM 10i PCB 2-layer 25mil 0.635mm Pure Gold No Legend No Solder Mask with Via Plating

Rogers TMM 10i PCB 2-layer 25mil 0.635mm Pure Gold No Legend No Solder Mask with Via Plating

1.Introduction

Introducing the cutting-edge Rogers TMM10i isotropic thermoset microwave material, a revolutionary ceramic thermoset polymer composite meticulously crafted for the most demanding high-frequency applications. With an exceptional isotropic dielectric constant (Dk),TMM 10i PCB offers unparalleled flexibility for strip-line and micro-strip designs, combining the best aspects of ceramic and PTFE substrates with the ease of soft substrate processing techniques.

2.Construction Details

The TMM 10i 25 mil substrate PCB is meticulously engineered to precision, utilizing the highest quality materials and strict manufacturing standards to provide optimal performance. Let's delve deeper into the construction details of this advanced PCB:

3.PCB Stack-up

4.PCB Statistic

5.Exceptional Features and Benefits

5.1 Features of TMM10i PCB

1)Impressive Electrical Properties:

With a dielectric constant (Dk) of 9.80 +/- .245, and a low dissipation factor of .0020 at 10GHz, this PCB ensures exceptional signal integrity and performance.

2)Thermal Stability:

The thermal coefficient of Dk of -43 ppm/°K and a matched coefficient of thermal expansion to copper ensure stability in varying thermal conditions, making it ideal for high-temperature environments.

3)Superior Mechanical Strength:

Designed to resist creep and cold flow, this PCB ensures long-lasting reliability and performance under demanding conditions.

4)Thermal Conductivity:

With a thermal conductivity of 0.76W/mk, this PCB efficiently dissipates heat, ensuring optimal performance in power-intensive applications.

5.2 Benefits of TMM10i PCB

1)Enhanced Reliability:

The TMM10i PCB is resistant to process chemicals, reducing damage during fabrication and ensuring long-term reliability in critical applications.

2)Ease of Processing:

This material eliminates the need for sodium naphthanate treatment before electroless plating, streamlining your manufacturing processes for increased efficiency.

3)Wire-Bond Compatibility:

Based on a thermoset resin, this PCB allows for reliable wire bonding, facilitating seamless integration with a variety of circuit components.

4)Versatile Applications:

From RF and microwave circuitry to satellite communication systems, chip testers, and more, the TMM10i PCB is your go-to solution for a wide range of cutting-edge applications.

6.Applications

The TMM10i TMM Series PCB is tailored for a diverse array of high-frequency applications, including:

RF and microwave circuitry

Power amplifiers and combiners

Filters and couplers

Satellite communication systems

Global Positioning Systems Antennas

Patch Antennas

Dielectric polarizers and lenses

Chip testers

In Conclusion

The TMM 10i high frequency PCB stands as a pinnacle of modern engineering, combining innovative design with top-tier performance to meet and exceed the requirements of the most demanding RF and microwave applications. With exceptional electrical properties, unmatched thermal stability, and reliable mechanical strength, this Rogers TMM PCB is your gateway to the future of high-frequency technology. Experience the pinnacle of performance with the TMM10i PCB, your partner in innovation and.
