Product Overview

The RT/duroid 6002 PCB is a high-performance, 2-layer rigid printed circuit board designed for RF, microwave, and high-frequency applications. Utilizing Rogers 6002 as the base material, this RTduroid 6002 PCB offers exceptional electrical stability, low signal loss, and outstanding thermal performance, making it ideal for aerospace, defense, telecommunications, and radar systems.

Detailed PCB Specifications

1. PCB Construction & Material Properties

2. PCB Stackup Structure

3. PCB Statistics

4. Manufacturing & Quality Standards

Artwork Format: Gerber RS-274-X

Compliance Standard: IPC-Class-2

Global Availability: Worldwide

RT/duroid 6002 Material: Key Features & Benefits

1. Exceptional High-Frequency Performance

• Low Dielectric Constant (Dk): 2.94±0.04 (stable across frequency bands)
• Ultra-Low Loss Tangent (Df): 0.0012 @ 10 GHz (minimizes signal loss in RF/microwave circuits)
• Low Thermal Coefficient of Dk: 12 ppm/°C (stable performance under temperature variations)

2. Superior Thermal & Mechanical Stability

• Thermal Conductivity: 0.6 W/m/K (efficient heat dissipation)
• Decomposition Temperature (Td): 500°C (TGA) (suitable for high-reliability applications)
• Low Moisture Absorption: 0.02% (prevents performance degradation in humid environments)
• CTE Matched to Copper: 24 ppm/°C (Z-axis) (reduces risk of delamination and warping)

3. Reliability for Demanding Environments

• Low Outgassing: Ideal for space and aerospace applications (NASA & ESA compliant)
• Excellent Dimensional Stability: Tight thickness control (±2%) for high-precision RF designs
• Consistent Impedance Control: Essential for high-speed digital and microwave circuits
•

Why Choose This RT/duroid 6002 PCB?

1. Optimized for High-Frequency & RF Applications

• Low signal loss ensures high signal integrity in 5G, radar, and satellite communications.
• Stable Dk over temperature makes it ideal for phased-array antennas and beamforming networks.

2. Precision Manufacturing for Complex Designs

• 5mil trace/space capability supports high-density interconnects (HDI).
• Immersion Tin finish provides excellent solderability and oxidation resistance.

3. High Reliability for Aerospace & Defense

• Low outgassing meets space application requirements.
• Consistent performance in extreme thermal and mechanical conditions.

Typical Applications

This Rogers 6002 5mil PCB is engineered for mission-critical high-frequency systems, including:

✅Phased Array Antennas (Military & Satellite Communications)

✅Radar Systems (Airborne & Ground-Based)

✅Global Positioning System (GPS) Antennas

✅Power Backplanes for High-Speed Data Transmission

✅Commercial & Military Avionics (Collision Avoidance Systems)

✅Beamforming Networks (5G & mmWave Technologies)

Ordering & Customization Options

Available for immediate shipment worldwide

Custom stackups, layer counts, and finishes available upon request

Conclusion

The RT/duroid 6002 Rogers PCB is a high-performance, low-loss solution for RF, microwave, and aerospace applications. With exceptional electrical properties, thermal stability, and manufacturing precision, it is the ideal choice for engineers requiring reliable high-frequency performance.

For custom requirements, bulk orders, or technical support, contact our sales team today!
