What Are the Key Features of RO3003 PCB?

In the realm of cutting-edge electronics, precision and reliability are paramount. Introducing the Rogers 3003 PCB, a high-performance substrate designed to elevate your RF and microwave applications to new heights. Crafted with ceramic-filled PTFE composites, the RO3003 60mil PCB embodies a fusion of technological prowess and unwavering stability. Let's delve into the intricacies of this exceptional PCB and explore how it can revolutionize your projects.

What are the key features of RO3003 PCB?

The RO3003 high frequency PCB stands as a testament to innovation in high-frequency laminates. Engineered for commercial microwave and RF applications, this substrate boasts remarkable features that set it apart in the realm of advanced electronics. Noteworthy attributes include:

1)Dielectric Constant Stability:

With a dielectric constant of 3+/- 0.04 at 10 GHz/23°C, the RO3003 PCB ensures consistent performance across varying temperatures and frequencies.

2)Exceptional Dissipation Factor:

Sporting a dissipation factor of 0.001 at 10 GHz/23°C, this PCB minimizes signal loss, making it ideal for high-frequency applications up to 77 GHz.

3)Thermal Resilience:

With a Td exceeding 500°C and a thermal conductivity of 0.5 W/mK, the RO3003 PCB thrives in demanding environments, ensuring reliable operation under extreme conditions.

4)Dimensional Stability:

The PCB's low in-plane expansion coefficient and moisture absorption of 0.04% guarantee exceptional dimensional stability, crucial for applications sensitive to temperature variations.

Embracing the Benefits of RO3003

The advantages of the RO3003 60mil Rogers PCB material extend beyond its technical specifications. Here's how this high-frequency substrate can revolutionize your designs:

1)Mechanical Robustness:

Enjoy unparalleled mechanical properties that endure the test of time, enabling reliable stripline and multi-layer board constructions.

2)Dielectric Consistency:

Benefit from uniform mechanical properties across a spectrum of dielectric constants, facilitating versatile multi-layer board designs.

3)Stable Performance:

Experience a stable dielectric constant versus temperature and frequency, making the RO3003 high frequency laminate pcb board an ideal choice for critical components like bandpass filters and microstrip patch antennas.

4)Manufacturing Efficiency:

Leveraging a volume manufacturing process and economical pricing, this PCB streamlines production without compromising quality.

Peering into the PCB Construction

The RO3003 high frequency circuit board comes to life in a meticulously crafted 2-layer rigid PCB configuration, featuring a copper layer thickness of 35 μm on each side. With a 60mil 1.524mm Rogers RO3003 substrate, this PCB embodies precision and reliability. Key construction details include:

Board Dimensions: 63mm x 35mm

Minimum Trace/Space: 4/6 mils

Minimum Hole Size: 0.3mm

Finished Board Thickness: 1.6mm

Surface Finish: Immersion Gold

Applications and Beyond

The versatility of the RO3003 60mil Rogers high frequency laminates PCB extends to a myriad of applications, including:

Automotive Radar Systems

Global Positioning Satellite Antennas

Cellular Telecommunications Infrastructure

Wireless Communication Antennas

Direct Broadcast Satellites

Remote Meter Readers

Power Backplanes

Conclusion: Unleash the Potential with RO3003

In conclusion, the Rogers RO3003 PCB embodies a harmonious blend of cutting-edge technology and unwavering reliability. Whether you're venturing into automotive radar systems or satellite communications, this high-frequency substrate is your gateway to innovation. Explore the possibilities with the RO3003 PCB and redefine the boundaries of high-frequency electronics.

For more information on the RO3003 Rogers substrates PCB and to explore its applications, contact us today. Unleash the power of innovation with Rogers RO3003.
