Product Overview

The F4BTMS220 2-layer 5 mil thick PCB represents the pinnacle of precision circuit board engineering, tailor-made for mission-critical applications demanding uncompromising reliability and high-frequency performance. Leveraging the cutting-edge F4BTMS material platform—an advanced upgrade from the proven F4BTM series—this DK2.2 F4B PCB delivers exceptional electrical stability, thermal resilience, and structural precision. Engineered to replace comparable imported alternatives, it serves as a robust hardware backbone for aerospace, military, and high-end communication systems, where failure is not an option.

1. PCB Construction Details

The following table outlines the physical specifications, manufacturing standards, and quality control measures that define the F4BTMS220 PCB’s precision.

2. PCB Stackup

Designed for optimal signal integrity and lightweight performance, the 2-layer rigid stackup is structured as follows:

3. PCB Statistics

These metrics reflect the board’s component density and connectivity design, optimized for precision assembly.

The F4BTMS220 Advantage

What truly sets the F4BTMS220 high frequency PCB apart is its core material—the F4BTMS PCB series, an upgraded iteration of the proven F4BTM platform. This material represents a technological leap, achieved through innovative formulation: a synergistic blend of polytetrafluoroethylene resin, high-load nano-ceramics, and ultra-thin glass fiber cloth. This unique composition solves two critical industry challenges: minimizing glass fiber-induced electromagnetic interference and reducing dielectric loss, making it ideal for microwave and RF applications.

Key Features of the F4BTMS220 Material:

1)Exceptional Signal Integrity: A stable Dielectric Constant (Dk) of 2.2±0.02 @ 10 GHz ensures predictable performance across the board.

2)Ultra-Low Loss: An incredibly low Dissipation Factor (Df) of 0.0009 @ 10 GHz (0.001 @ 20 GHz) minimizes signal attenuation, making it perfect for high-speed and high-frequency designs.

3)Superior Thermal & Dimensional Stability: A low thermal coefficient of Dk (-130 ppm/°C) and controlled CTE (X: 40, Y: 50, Z: 290 ppm/°C) ensure stable electrical performance across a wide temperature range (-55°C to 288°C).

4)High Reliability: The material is rated UL 94 V-0 and exhibits extremely low moisture absorption (0.02%), guaranteeing performance and longevity in harsh environments.

5)Low Profile & High Strength: The use of ultra-fine materials allows for a remarkably thin and rigid 5mil core without sacrificing mechanical integrity.

Typical Applications

The F4BTMS220 2-layer PCB is the preferred choice for:

• Aerospace equipment and cabin systems
• Microwave and RF communication modules
• Military radar and phased array antennas
• Satellite communication and feed networks

When your design can’t afford compromise, the 5 mil F4BTMS220 PCB delivers the performance, reliability, and support you need to stay ahead of the curve.
