Home High Temperature PCB RF-35 High Tg High Frequency 30mil Double Sided PCB Immersion Gold and Black Solder Mask

RF-35 High Tg High Frequency 30mil Double Sided PCB Immersion Gold and Black Solder Mask


It’s 120mm long by 60mm wide with immersion gold on pads. Bottom layer is open to air with gold surface as we’ve seen.




  • Item NO.:

    BIC-172-v131.0
  • Order(MOQ):

    1-10
  • Payment:

    T/T
  • Price Range:1 - 50/$99
  • Price Range:1 - 50/$2.9
  • Product Origin:

    China
  • Color:

    White
  • Shipping Port:

    Shenzhen
  • Lead Time:

    7-10 days
  • Product Detail

RF-35 High Tg High Frequency PCB 30mil Double Sided Printed Circuit Board Coating Immersion Gold and Black Solder Mask

(Printed Circuit Boards are custom-made products, the picture and parameters shown are just for reference)


Brief Introduction:


This is a type of ORCER (Organic Ceramic) RF-35 high frequency PCB. It’s built on 30mil core with 2oz copper on both top and bottom layer(double sided board).

Taconic RF PCB

Besides RF-35, there’re other types of Taconic “RF” PCB available in our house. Such as RF-10(10mil,20mil, 25mil, 60mil and 125mil), RF-30A(10mil, 20mil, 30mil,40mil and 60mil), RF-35TC(10mil, 20mil, 30mil), RF-60TC(10mil, 20mil, 30mil, 60mil and 125mil), RF-35A2 (5mil, 10mil, 20mil, 30mil and 60mil) etc. DK ranges 2.97 to 10.2 etc.


2L RF-35 30mil PCB


PCB Specifications:


PCB SIZE 120 x 60mm=1up
BOARD TYPE Double sided PCB
Number of Layers 2 layers
Surface Mount Components YES
Through Hole Components NO
LAYER STACKUP copper ------- 35um(1 oz)+plate TOP layer
RF-35 0.762mm
copper ------- 35um(1 oz) + plate  BOT Layer
TECHNOLOGY
Minimum Trace and Space: 7.0 mil / 7.0 mil
Minimum / Maximum Holes: 0.5 mm / 0.5 mm
Number of Different Holes: 1
Number of Drill Holes: 8
Number of Milled Slots: 1
Number of Internal Cutouts: 1
Impedance Control: no
Number of Gold finger: 0
BOARD MATERIAL
Glass Epoxy:  RF-35 0.762mm
Final foil external:  2.0 oz
Final foil internal:  N/A
Final height of PCB:  0.8 mm ±0.1
PLATING AND COATING
Surface Finish Immersion gold, 75%
Solder Mask Apply To:  Top Layer
Solder Mask Color:  Black
Solder Mask Type: Kuangshun
CONTOUR/CUTTING Routing
MARKING
Side of Component Legend Top Layer
Colour of Component Legend White
Manufacturer Name or Logo:  N/A
VIA Plated through hole(PTH), minimum size 0.5mm.
FLAMIBILITY RATING 94V-0
DIMENSION TOLERANCE
Outline dimension:   0.0059"
Board plating: 0.0029"
Drill tolerance:  0.002"
TEST 100% Electrical Test prior shipment
TYPE OF ARTWORK TO BE SUPPLIED email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA Worldwide, Globally.


Other PCB Available Material:


FR-4 Tg>135, High Tg>170 FR-4 ( S1000-2M, TU-872 SLK, TU-768, IT-180A etc.)

Rogers RO4350B, RO4003C, RO4730G3, RO4360G2, RO3003, RO3035, RO3006, RO3010, RO3210, RO3203, etc.

Rogers RT/duroid 5880, RT/duroid 5870, RT/duroid 6002, RT/duroid 6010, RT/duroid 6035HTC etc.

Rogers TMM4, TMM10, Kappa 438 etc.

PTFE F4B (DK2.2, DK2.65, DK2.85, DK2.94, DK3.0, DK3.2, DK3.38, DK3.5, DK4.0, DK4.4, DK6.15, DK10.2)

Taconic TLX-0, TLX-9, TLX-8, TLX-7, TLX-6, TLY-5, TLY-3, RF-35TC, TLF-35, RF-60A, RF-60TC, RF-35A2 etc.

AD450, AD600, TC350 etc.

Nelco N4000, N9350, N9240

Metal core PCB, 1W/MK-3W/MK material

Flexible PCB


CAPABILITY:


2500-3000 types each month.


SERVICE AREA:


North America, Oceania, Southeast Asia, Eastern Europe, Africa, Latin America, Western & Southern Europe, Northern Europe, Central & South Asian, Middle East.


Applications:

Power Amplifiers

Filters and Couplers

Passive Components


BICHNEG PCB WORKSHOP:


BICHNEG PCB WORKSHOP


BICHNEG PCB CERTIFICATION:


BICHNEG PCB CERTIFICATION


BICHENG PCB MAIN COURIERS:


BICHENG PCB MAIN COURIERS
