RT/duroid 6035HTC PCB 10mil 2-layer Rogers High Frequency Board

RT/duroid 6035HTC PCB 10mil 2-layer Rogers High Frequency Board

Introduction:

Introducing the RT/duroid 6035HTC PCB, a high-performance circuit material designed for high power RF and microwave applications. Developed by Rogers, a renowned leader in advanced materials, the RT/duroid 6035HTC 10mil PCB combines ceramic-filled PTFE composites with exceptional thermal conductivity and superior long-term stability. This innovative PCB offers significant advantages over standard high thermally conductive laminates, making it the ideal choice for demanding high power applications.

Features:

The RT/duroid 6035HTC PCB boasts a range of impressive features that contribute to its exceptional performance:

1.DK of 3.5 +/- 0.05 at 10 GHz/23°C:

This high dielectric constant ensures efficient signal propagation and optimal electrical performance, making it ideal for high frequency applications.

2.Dissipation factor of 0.0013 at 10 GHz/23°C:

With an extremely low loss tangent, this PCB minimizes signal loss and provides excellent high frequency performance.

3.Thermal Coefficient of dielectric constant of -66 ppm/°C:

The RT/duroid 6035HTC exhibits remarkable stability even under varying temperature conditions, ensuring consistent performance over time.

4.Moisture Absorption 0.06%:

The low moisture absorption rate of this PCB enhances its reliability, making it suitable for applications where moisture resistance is critical.

5.Thermal Conductivity of 1.44 W/m/K at 80°C:

The high thermal conductivity of the RT/duroid 6035HTC enables efficient heat dissipation, allowing for lower operating temperatures in high power applications.

6.CTE in X-axis of 19 ppm/°C, Y-axis of 19 ppm/°C, and Z-axis of 39 ppm/°C:

The balanced coefficient of thermal expansion across different axes ensures dimensional stability and minimizes the risk of failure due to thermal stress.

Benefits:

The 10mil RT/duroid 6035HTC PCB offers several advantages that set it apart from other circuit materials:

1.High Thermal Conductivity:

The enhanced thermal conductivity of this PCB enables efficient heat dissipation, resulting in lower operating temperatures for high power applications. This feature not only improves performance but also extends the lifespan of components.

2.Low Loss Tangent:

 With its low dissipation factor and loss tangent, the RT/duroid 6035HTC PCB ensures minimal signal loss and distortion, making it ideal for high-frequency applications that require excellent signal integrity.

3.Thermally Stable Low Profile and Reverse Treat Copper Foil:

The use of high-quality copper foil with thermal stability ensures lower insertion loss and excellent thermal performance for the PCB. This feature enhances the reliability and durability of the circuit.

4.Advanced Filler System:

The RT/duroid 6035HTC PCB incorporates an advanced filler system that improves drillability and extends tool life compared to circuit materials containing alumina fillers. This leads to cost savings and increased efficiency during the manufacturing process.

PCB Specifications:

The RT/duroid 6035HTC PCB comes in a 2-layer rigid construction with the following specifications:

Quality Assurance and Standard Compliance:

To ensure the highest quality and adherence to industry standards, every RT/duroid 6035HTC PCB undergoes rigorous testing and meets the IPC-Class-2 standard. This ensures the reliability, performance, and consistency of the PCB in various applications.

PCB Statistics:

The RT/duroid 6035HTC PCB features a comprehensive set of statistics that highlight its capabilities:

Availability:

The RT/duroid 6035HTC PCB is available worldwide, ensuring accessibility for customers across the globe. Whether you are located in North America, Europe, Asia, or any other region, you can rely on prompt and efficient delivery of this high-quality circuit material.

Typical Applications:

The RT/duroid 6035HTC PCB finds its application in a wide range of high-power RF and microwave circuits, including:

1.High power RF and microwave amplifiers:

The exceptional thermal conductivity and low loss tangent of this PCB make it ideal for high-power amplifiers, ensuring efficient heat dissipation and optimal signal performance.

2.Power amplifiers, couplers, filters, combiners, power dividers:

The RT/duroid 6035HTC PCB excels in applications that require high power handling, low loss, and stable electrical characteristics, making it suitable for various power-related components.

Conclusion:

The RT Duroid 6035HTC high frequency PCB is a cutting-edge circuit material designed for high power RF and microwave applications. With its superior thermal conductivity, low loss tangent, and advanced filler system, this PCB offers unparalleled performance and reliability. It meets the industry's highest standards and provides excellent electrical characteristics, ensuring optimal signal integrity and longevity. Whether you are working on high power RF amplifiers or complex microwave circuits, the Rogers 6035HTC PCB is the ideal choice to achieve exceptional results. Experience the power of advanced materials with the RT/duroid 6035HTC PCB.
