This 18-Layer RO4350B RO4450F Multilayer PCB is a high-performance solution for demanding RF, microwave, and high-power applications.
Item NO.:
BIC-324-v403.0Order(MOQ):
1-10Payment:
T/TProduct Origin:
ChinaShipping Port:
ShenzhenLead Time:
7-10 days
18-Layer RO4350B Rogers 4350BPCB 3.2mm Thick ENIG Selective Hard Gold Multilayer Board
Our 18-Layer RO4350B PCB is engineered for high-frequency RF/microwave applications, offering superior signal integrity, thermal stability, and durability. Designed with Rogers RO4350B laminate and RO4450F bondply, this RO4350B multilayer PCB ensures low signal loss, tight impedance control, and excellent thermal management, making it ideal for 5G infrastructure, aerospace, automotive radar, and military communications.
Featuring a 3.2mm thick multilayer PCB construction,ENIG Selective Hard Gold surface finish, this resin-filled vias PCB is built for high-reliability applications requiring exceptional electrical performance and mechanical robustness.
Key Features & Specifications
1. PCB Construction & Material Properties
|
PCB Construction Details |
||
|
Category |
Parameter |
Value / Specification |
|
Base Material |
Material Type |
RO4350B + RO4450F |
|
Layer Count |
Total Layers |
18 layers |
|
Board Dimensions |
Length x Width |
218 mm x 497 mm=1PCS, ±0.15mm |
|
Trace/Space |
Minimum Trace/Space |
4/4 mils |
|
Hole Specifications |
Minimum Hole Size |
0.4mm |
|
Blind Vias |
L11-L18 (mechanical drill) |
|
|
Via in Pad |
Required |
|
|
Press-Fit Holes |
Required |
|
|
Board Thickness |
Finished Thickness |
3.2mm |
|
Copper Weight |
Inner Layers |
1oz (1.4 mils) |
|
Outer Layers |
1oz (1.4 mils) |
|
|
Via Plating |
Plating Thickness |
20 µm |
|
Via Treatment |
Resin filled and capped |
|
|
Surface Finish |
Primary |
Immersion Gold (ENIG) |
|
Secondary |
Selective Hard Gold (50 µinch) |
For specific areas (e.g., connectors) |
|
Solder Mask |
Top/Bottom Color |
Blue |
|
Silkscreen |
Top/Bottom Color |
White |
|
Testing |
Electrical Test |
100% tested prior to shipment |
2. PCB Stackup Structure
|
18-Layer PCB Stackup |
||||
|
Layer |
Material |
Copper (μm) |
Type |
Notes |
|
Layer 1 (Top) |
Copper |
35 (1 oz) |
Signal |
Outer layer |
|
Rogers RO4350B Core |
0.102 mm (4 mil) |
Dielectric |
High-frequency material |
|
|
Layer 2 |
Copper |
35 (1 oz) |
Signal/Power |
|
|
RO4450F Bondply |
0.102 mm (4 mil) |
Prepreg |
Adhesive layer |
|
|
Layer 3 |
Copper |
35 (1 oz) |
Signal |
|
|
Rogers RO4350B Core |
0.102 mm (4 mil) |
Dielectric |
|
|
|
Layer 4 |
Copper |
35 (1 oz) |
Signal/Power |
|
|
RO4450F Bondply |
0.102 mm (4 mil) |
Prepreg |
|
|
|
... |
... |
... |
... |
(Repeat pattern as needed) |
|
Layer 15 |
Copper |
35 (1 oz) |
Signal |
|
|
Rogers RO4350B Core |
0.102 mm (4 mil) |
Dielectric |
|
|
|
Layer 16 |
Copper |
35 (1 oz) |
Signal/Power |
|
|
RO4450F Bondply |
0.102 mm (4 mil) |
Prepreg |
|
|
|
Layer 17 |
Copper |
35 (1 oz) |
Signal |
|
|
Rogers RO4350B Core |
0.102 mm (4 mil) |
Dielectric |
|
|
|
Layer 18 (Bottom) |
Copper |
35 (1 oz) |
Signal |
Outer layer |
PCB Statistic
|
Category |
Count |
|
Components |
651 |
|
Total Pads |
779 |
|
Through-Hole Pads |
338 |
|
Top SMT Pads |
262 |
|
Bottom SMT Pads |
179 |
|
Vias |
632 |
|
Nets |
12 |
3.Advanced Material Properties: RO4350B & RO4450F
3.1 Introduction to RO4350B Core Material
Rogers 4350B materials are proprietary woven glass reinforced hydrocarbon/ceramic laminates with electrical performance close to PTFE/woven glass while offering the manufacturability of epoxy/glass. These RO4350B laminates provide tight control over dielectric constant (Dk) and maintain low loss characteristics while utilizing standard epoxy/glass processing methods.
Key advantages of RO4350B include:
3.2 Introduction to RO4450F Bondply
The Rogers RO4450F bondplys are specially engineered for multi-layer constructions with RO4000 series laminates. These bondplys offer:
3.3 Material Performance Characteristics
RO4350B Core Features:
RO4450F Bondply Features:
Why Choose This 18-Layer RO4350B PCB?
1. Superior High-Frequency Performance
2. Robust Mechanical & Thermal Stability
3. Advanced Surface Finishes for Durability
ENIG (Electroless Nickel Immersion Gold):
Selective Hard Gold (50 µin):
4. Optimized for Complex RF & Power Applications
Typical Applications
✔5G Base Stations & Antennas
✔Automotive Radar (77GHz ADAS, LiDAR)
✔Aerospace & Defense (Radar, Avionics)
✔Satellite Communications (LNB, Phased Arrays)
✔High-Power RF Amplifiers
✔Medical Imaging & Industrial Sensors
Quality Assurance & Global Availability
100% Electrical Testing before shipment
IPC-Class-2 Compliance for high-reliability standards
Worldwide Shipping with fast lead times
Conclusion
This 18-Layer RO4350B RO4450F Multilayer PCB is a high-performance solution for demanding RF, microwave, and high-power applications. With ultra-low loss, superior thermal management, and advanced surface finishes, it is the ideal choice for 5G, automotive radar, aerospace, and defense systems.
Contact us today for custom Rogers RO4350B PCB solutions tailored to your project requirements!
