Introduction

Introducing the RO4360G2 PCB 8mil, a cutting-edge printed circuit board (PCB) that combines the exceptional performance ofRogers RO4360G2 laminateswith the convenience and flexibility of FR-4 processing. This 2-layer rigid PCB is a low-loss, glass-reinforced, hydrocarbon ceramic-filled thermoset material that offers excellent balance in terms of performance and processing capabilities. With its superior characteristics and cost-effective design, the RO4360G2 PCB is a top choice for a wide range of high-frequency electronic applications.

PCB Construction Details

PCB Stackup

PCB Stackup:  2-layer rigid PCB

Copper_layer_1 - 35μm

Rogers RO4360G2 Substrate - 8mil (0.203mm)

Copper_layer_2 - 35μm

PCB Statistic

Features

The Rogers RO4360G2 PCB offers a range of impressive features that set it apart from conventional PCBs:

1.Dielectric constant of 6.15+/- 0.15 at 10 GHz/23°C:

Ensures outstanding signal integrity and minimal signal loss in high-frequency applications.

2.Dissipation factor of 0.0038 at 10 GHz/23°C:

Reduces energy loss, delivering efficient and reliable performance.

3.High thermal conductivity of 0.75 W/mK:

Efficiently dissipates heat, enabling optimal thermal management in demanding applications.

4.Low Z-axis coefficient of thermal expansion at 28 ppm/°C:

Ensures dimensional stability, minimizing the risk of mechanical failure under varying temperature conditions.

5.Copper-matched coefficient of thermal expansion:

Exhibits compatibility with copper conductors, maintaining the structural integrity and reliability of the PCB.

6.Lead-free process compatible, 94V-0 flammability:

Complies with industry regulations and environmental standards, offering a sustainable and safe solution.

Benefits

The RO4360G2 high frequency PCB offers numerous advantages for electronic designers and manufacturers:

1.Design flexibility:

With its superior electrical performance and compact size, this PCB enables designers to realize intricate and space-efficient designs.

2.Plated through-hole reliability:

The RO4360G2 PCB 8mil ensures robust connections and enhanced reliability, making it ideal for demanding applications.

3.Automated assembly compatibility:

The PCB's design and construction facilitate automated manufacturing processes, improving efficiency and reducing production costs.

4.Environmentally friendly:

As a lead-free process compatible PCB, it minimizes environmental impact and complies with the latest regulatory requirements.

5.Efficient supply chain and short lead times:

The RO4360G2 PCB 8mil is readily available worldwide, ensuring quick and cost-effective access to high-quality materials.

Typical Applications

The versatility and exceptional performance of the RO4360G2 8 mil substrate PCB  make it suitable for various applications, including:

-Base Station Power Amplifiers

-Small Cell Transceivers

Conclusion

In summary, the Rogers 4360G2 PCB offers a state-of-the-art solution for electronic applications that demand high performance, reliability, and design flexibility. With its exceptional characteristics, this Rogers PCB empowers engineers to create innovative and cutting-edge electronic products while ensuring efficiency, durability, and cost-effectiveness. Experience the advantages of the RO4360G2 PCB 8mil for your next project and unlock new possibilities in electronic design and manufacturing.
