Rogers RT/duroid 5880LZ PCB 20mil 2-layer High Frequency Circuit Board
Introduction
Rogers 5880LZ laminates are a revolutionary solution designed for demanding strip-line and micro-strip circuit applications. These RT duroid 5880LZ laminates incorporate a unique filler, resulting in a low-density, lightweight material that guarantees exceptional performance and caters to weight-sensitive applications. With a remarkably low dielectric constant and dissipation factor, RT/duroid 5880LZ is perfect for applications in the Ku-band and beyond.
Features
The RT/duroid 5880LZ 20mil substrate PCB boasts an impressive array of features, making it an ideal choice for high-performance projects:
2.1 Dielectric Constant (DK):
With a DK of 2.0 +/- 0.04 at 10 GHz/23°C, this PCB offers outstanding electrical properties, ensuring reliable signal integrity and reduced impedance variations.
2.2 Low Dissipation Factor:
The PCB exhibits a low dissipation factor ranging from .0021 to .0027 at 10GHz/23°C. This ensures efficient power delivery and minimizes signal loss, making it suitable for high-frequency applications.
2.3 Low Z-Axis Coefficient of Thermal Expansion:
With an exceptionally low coefficient of thermal expansion (40 ppm/°C), this PCB remains stable even under temperature fluctuations, reducing the risk of warpage and solder joint failure.
2.4 Outgassing TML, CVCM, and WVR:
The RT/duroid 5880LZ PCB 20mil undergoes rigorous testing to ensure it meets stringent standards. With TML, CVCM, and WVR levels at 0.01%, it guarantees low outgassing, making it ideal for applications in demanding environments.
2.5 Lightweight and Low Density:
Weighing only 1.4 gm/cm³, this PCB not only delivers remarkable performance but also helps reduce the overall weight of your product. It is perfect for weight-sensitive applications that require top-tier performance without compromising on mass.
2.6 UL 94V-0 Flammability:
Ensuring a high level of safety, the RT/duroid 5880LZ PCB 20mil meets the UL 94V-0 flammability standard. It provides peace of mind and compliance with safety regulations.
2.7 Lead-Free Process Compatible:
The PCB is designed to be compatible with lead-free manufacturing processes. This feature aligns with environmental regulations while ensuring high-quality production.
Benefits
By choosing the RT/duroid 5880LZ Rogers PCB , you unlock numerous advantages for your project:
3.1 Lightweight and Low Density:
The PCB's low weight and density ensure a lighter end product, making it ideal for aerospace and other weight-sensitive applications.
3.2 Uniform Electrical Properties:
The PCB guarantees consistent electrical performance across a wide frequency range. This uniformity ensures reliable signal transmission and reception, reducing the need for impedance matching adjustments.
3.3 Solvent and Reagent Resistance:
RT/duroid 5880LZ laminates are highly resistant to solvents and reagents commonly used in etching or plating processes. This resistance ensures the durability and longevity of the PCB, even in harsh operating environments.
Construction Details
The Rogers RT/duroid 5880LZ PCB 20mil features a precise construction to meet the requirements of your project:
Stackup:Designed as a 2-layer rigid PCB, the construction comprises the following layers:
Copper Layer 1: 35μm
RT/duroid 5880LZ: 0.508 mm (20mil)
Copper Layer 2: 35μm
Construction Details |
Specifications |
Board Dimensions |
90.63mm x 170.35mm (+/- 0.15mm) |
Minimum Trace/Space |
4/5 mils |
Minimum Hole Size |
0.2mm |
Blind Vias |
No |
Finished Board Thickness |
0.6mm |
Finished Cu Weight |
1oz (1.4 mils) outer layers |
Via Plating Thickness |
20 μm |
Surface Finish |
OSP |
Top Silkscreen Color |
White |
Bottom Silkscreen Color |
Green |
Top Solder Mask |
No |
Bottom Solder Mask |
No |
Electrical Test |
100% prior to shipment |
PCB Statistics
The Rogers 5880LZ PCB incorporates the following statistics, highlighting its versatility and adaptability:
PCB Statistics |
Values |
Components |
29 |
Total Pads |
120 |
Thru Hole Pads |
93 |
Top SMT Pads |
27 |
Bottom SMT Pads |
0 |
Vias |
56 |
Nets |
2 |
Artwork and Standards
To guarantee seamless integration into your manufacturing process, the RT/duroid 5880LZ PCB 20mil accepts Gerber RS-274-X artwork, adhering to the IPC-Class-2 standard—a widely accepted industry benchmark for PCB quality and reliability.
Availability
We are proud to offer the RT/duroid 5880LZ PCB worldwide, ensuring our customers from all corners of the globe can benefit from its exceptional performance and reliability.
Typical Applications
The versatility of the RT/duroid 5880LZ High frequency PCB makes it the preferred choice for a wide range of applications, including but not limited to:
Airborne antenna systems
Lightweight feed networks
Radar systems
Guidance systems
Point-to-point digital radio antennas
Conclusion
In conclusion, the RT/duroid 5880LZ PCB 20mil Rogers substrate embodies excellence and innovation in the world of printed circuit boards. Its exceptional features, construction details, and compatibility with industry standards make it an optimal choice for demanding applications in aerospace, telecommunications, and high-frequency systems. Embrace the advantages of RT/duroid 5880LZ and unlock the full potential of your designs.
