SF201 Polyimide Flexible PCB With a dielectric constant of less than 3.7 and a dissipation factor of less than 0.01 at 10 GHz, optimal signal integrity and transmission efficiency are ensured.
Item NO.:
BIC-227-v278.0Order(MOQ):
1-10Payment:
T/TProduct Origin:
ChinaShipping Port:
ShenzhenLead Time:
7-10 days
SF201 Polyimide Flexible PCB 1-layer 1mil
Introduction
The SF201 series materials, known for their exceptional quality and performance, are utilized in our SF201 Polyimide Flexible PCB. With a dielectric constant of less than 3.7 and a dissipation factor of less than 0.01 at 10 GHz, optimal signal integrity and transmission efficiency are ensured. Available in thicknesses of 12.5um, 20um, and 25um, with ED copper, RA Copper, and RTF copper options ranging from 12um to 70um, the SF201 FPC PI series offers unparalleled flexibility and customization.
Features
Loaded with a plethora of features that cater to the diverse needs of our customers, the SF201 Polyimide Flexible PCB boasts:
1.Excellent soldering reliability, dimensional stability, and chemical resistance, ensuring long-lasting performance and durability.
2.Superior flexibility and electrical properties, making it ideal for applications requiring bendability and reliability.
3.Halogen-free and flammability rated UL94 V-0, ensuring safety and compliance with industry standards.
4.Compliant with the EU RoHS directive, free of harmful substances such as Pb, Hg, Cd, Cr6+, PBB, and PBDE, making it environmentally friendly and safe for use.
PCB Construction Details
The SF201 Polyimide Flex PCB, a 1-layer flexible PCB, comes with the following specifications:
Items |
Specifications |
Board dimensions |
25mm x 21mm (±0.15mm) |
Minimum Trace/Space |
3/4 mils |
Minimum Hole Size |
0.25mm |
Blind vias |
No |
Finished board thickness |
0.03mm |
Finished Cu weight |
1oz (1.4 mils) outer layers |
Surface finish |
Immersion Gold |
Top Silkscreen |
No |
Bottom Silkscreen |
No |
Top Solder Mask |
No |
Bottom Solder Mask |
No |
100% Electrical Test |
Yes |
PCB Statistics
With the following statistics, the SF201 PI Flex PCB offers:
PCB Statistics |
Value |
Components |
3 |
Total Pads |
5 |
Thru Hole Pads |
0 |
Top SMT Pads |
5 |
Bottom SMT Pads |
0 |
Vias |
0 |
Nets |
1 |
Type of artwork supplied:
Gerber RS-274-X, ensuring compatibility with industry-standard design tools.
Quality standard:
IPC-Class-2, meeting stringent quality requirements and ensuring reliability.
Availability:Worldwide, providing global access to our cutting-edge PCB solutions.
Typical Applications
The SF201 Polyimide Flexible PCB finds applications in various industries and products, including:
1. Computers, for reliable and efficient circuitry.
2. Mobile phones, for compact and high-performance designs.
3. Digital cameras and VCRs, ensuring optimal signal processing and transmission.
4. Flat panel displays, for vibrant and high-quality visuals.
5. Apparatus and instruments, for precise and reliable electronic components.
6. Automotive electronics, for robust and durable circuitry in vehicles.
In conclusion, the SF201 Polyimide Flexible PCB 1-layer 1mil is a groundbreaking product that combines advanced technology with unparalleled reliability and performance. Whether a cutting-edge electronic device or a high-tech automotive application is being worked on, this PCB is sure to meet and exceed expectations. Experience the future of PCB technology with the SF201 series - a trusted partner for innovative solutions.
