The Aluminum T110 series is a testament to Totking's commitment to excellence, offering a range of exceptional features and benefits that set it apart from the competition.
Item NO.:
BIC-228-v279.0Order(MOQ):
1-10Payment:
T/TProduct Origin:
ChinaShipping Port:
ShenzhenLead Time:
7-10 days
T110 8oz Aluminum PCB 1-layer 1.2mm
Introducing Totking's T110 8oz Aluminum PCB - the pinnacle of quality, performance, and reliability for your electronic design projects. The T110 series is a testament to Totking's commitment to excellence, offering a range of exceptional features and benefits that set it apart from the competition. With a focus on durability, precision, and innovation, the 8oz Aluminum PCB is the ideal choice for engineers, designers, and manufacturers looking to take their projects to the next level.
The T110 series of PCBs from Totking encompasses a variety of metal substrates, including aluminum, ferrum, copper, and stainless steel. Each substrate is carefully selected to meet the specific requirements of your application, with options such as 1100, 3003, 5052, and 6061 aluminum substrates, SECC ferrum, 1100 copper, and SUS304 and SUS316 stainless steel. The thermal conductivity of the T110 series ranges from 1.0W/mk to 2.0W/mk, providing efficient heat dissipation and ensuring optimal performance.
Key Features of the T110 8oz Aluminum PCB:
1.Peel Strength:
The T110 PCB boasts a peel strength of 1.8 N/mm, ensuring that components remain securely in place even under extreme conditions.
2.Thermal Stress Resistance:
With a thermal stress tolerance of 90 seconds without delamination or bubbles, the T110 PCB is designed to withstand the rigors of modern electronics.
3.Electrical Properties:
The T110 PCB offers excellent surface resistivity and volume resistivity of 10^7 Mohm and 10^7 Mohm-cm respectively, as well as an electrical strength of 30 KV/mm, providing reliable insulation and protection for your components.
4.Tg and Flammability Rating:
The T110 PCB features a Tg of 100⊥and a flammability rating of V-0, UL94, ensuring stability and safety in high-temperature environments.
5.Water Absorption and CTI:
With a water absorption rate of just 0.03% and a CTI of 600V, the T110 PCB offers durable and reliable performance in a variety of conditions.
Benefits of Choosing the T110 8oz Aluminum PCB:
1.Good Heat Dissipation:
The T110 PCB is designed to effectively dissipate heat, ensuring that your components operate at optimal temperatures and prolonging their lifespan.
2.Excellent Insulation:
With outstanding surface and volume resistivity, the T110 PCB provides reliable insulation for your electronic circuits, protecting them from electrical interference.
3.Dimensional Stability:
The T110 PCB offers excellent dimensional stability, ensuring that your components remain securely in place and function as intended.
4.Good Machinability:
The T110 PCB is easy to customize and install, thanks to its good machinability, allowing you to tailor it to your specific project requirements.
5.Electromagnetic Wave Shielding:
The T110 PCB provides electromagnetic wave shielding, protecting your circuits from external interference and ensuring reliable performance in high-frequency environments.
6.Cost-Effectiveness:
The T110 PCB offers excellent cost-effectiveness, providing exceptional value for your investment without compromising on quality or performance.
Construction Details of the T110 8oz Aluminum PCB:
Item |
Details |
Board Dimensions |
80mm x 52mm +/- 0.15mm |
Minimum Trace/Space |
15/20 mils |
Minimum Hole Size |
1.0mm |
Blind Vias |
No |
Finished Board Thickness |
1.2mm |
Finished Cu Weight |
8oz (11.2 mils) outer layers |
Surface Finish |
OSP |
Top Silkscreen |
No |
Bottom Silkscreen |
No |
Top Solder Mask |
No |
Bottom Solder Mask |
No |
Electrical Test |
100% prior to shipment |
T110 8oz Aluminum PCB Statistics:
Item |
Details |
Components |
7 |
Total Pads |
9 |
Thru Hole Pads |
0 |
Top SMT Pads |
9 |
Bottom SMT Pads |
0 |
Vias |
0 |
Nets |
1 |
The T110 8oz Aluminum PCB is supplied as Gerber RS-274-X artwork and adheres to the IPC-Class-2 quality standard, guaranteeing top-tier performance and reliability. With worldwide availability, you can trust Totking to deliver the highest quality PCBs to meet your unique design needs.
Applications of the T110 8oz Aluminum PCB:
LED lighting circuits
Thick-film hybrid integrated circuits
Power circuits
Solid-state relays
Experience the difference with Totking's T110 8oz Aluminum PCB - the ultimate choice for quality, performance, and reliability in your electronic design projects. Elevate your designs with the T110 series and unlock the potential of your electronic creations. Contact us today to learn more about the T110 8oz Aluminum PCB and how it can take your projects to new heights. Trust Totking for exceptional PCB solutions that exceed your expectations.
