Welcome to the future of high-performance printed circuit boards (PCBs) with our newly shipped FR408HR TG190 4-Layer PCB. Designed for advanced applications requiring superior thermal reliability, electrical performance, and durability, this FR408HR 4-Layer PCB is engineered to meet the demands of modern electronics. Whether you're working on high-speed digital systems, networking equipment, or industrial instrumentation, this High-Speed PCB delivers unmatched quality and performance.

Crafted with Isola FR408HR laminate and FR408HR prepreg materials, this 4-layer PCB is a testament to cutting-edge technology. With a glass transition temperature (Tg) of 190°C, a low dielectric constant of 3.65 @ 10GHz, and a dissipation factor of 0.0095 @ 10GHz, thisFR408HR TG190 is optimized for high-frequency and high-speed applications. Its RoHS compliance, CAF resistance, and lead-free assembly compatibility make it an environmentally friendly and reliable choice for your projects.

Key Features

1. High-Performance Material:

• FR408HR laminate and prepreg with a patented multifunctional resin system ensures 30% improvement in Z-axis expansion and 25% more electrical bandwidth compared to competitors.
• Tg of 190°C ensures excellent thermal stability, making it ideal for high-temperature environments.
• Low dielectric constant and dissipation factor for superior signal integrity in high-speed and high-frequency applications.

2.Advanced Electrical Performance:

• Dielectric constant of 3.65 @ 10GHz and dissipation factor of 0.0095 @ 10GHz ensure minimal signal loss and high-speed signal transmission.
• CAF (Conductive Anodic Filament) resistance enhances reliability in humid environments.

3.Thermal Reliability:

• 6x 260°C reflow capable and 6x 288°C solder float capable for lead-free assembly processes.
• Time to Delaminate by TMA (unclad): T260 >60 minutes, T288 >30 minutes, ensuring long-term durability.

4.Compliance and Safety:

• RoHS compliant and UL-94 V0 flammability rating for safety and environmental standards.
• Laser fluorescing and UV blocking for compatibility with Automated Optical Inspection (AOI) systems.

Technical Specifications

PCB Stack-Up

PCB Statistics

Applications

The Isola FR408HR PCB is ideal for a wide range of high-performance applications, including:

-High-Density Interconnect (HDI) PCBs

-High-Speed Digital Circuits

-Networking and Communication Equipment

-Storage and Peripherals

-Medical, Industrial, and Instrumentation Devices

Why Choose Our FR408HR TG190 4-Layer PCB?

1.Superior Signal Integrity:

With a low dielectric constant and dissipation factor, this PCB ensures minimal signal loss, making it perfect for high-speed and high-frequency applications.

2.Exceptional Thermal Performance:

The high Tg of 190°C and excellent thermal reliability ensure stability in demanding environments.

3.Reliability and Durability:

CAF resistance, lead-free assembly compatibility, and UL-94 V0 rating make this PCB a reliable choice for long-term use.

4.Global Availability:

Available worldwide, this PCB meets IPC-Class-3 quality standards, ensuring the highest level of performance and reliability.

Conclusion

The FR408HR Multilayer PCB is a state-of-the-art solution for advanced electronic applications. With its high thermal reliability, superior electrical performance, and robust construction, it is the ideal choice for industries requiring high-speed, high-frequency, and high-density interconnect solutions.

Whether you're designing cutting-edge networking equipment, medical devices, or industrial instrumentation, this PCB delivers the performance and reliability you need. Explore the possibilities with our FR408HR TG190 High TG PCB and take your projects to the next level.

For more information or to place an order, contact us today!
