Introducing the RO3203 2-Layer 10 mil PCB—The high-performance circuit board designed to redefine reliability in high-frequency scenarios. Crafted with Rogers , a ceramic-filled PTFE composite reinforced with woven fiberglass, this Rogers 10mil PCB balances exceptional electrical performance, mechanical stability, and cost-effectiveness, making it the preferred choice for industries demanding precision beyond 20 GHz. Compliant with IPC-Class-2 standards, lead-free compatible, and backed by 100% electrical testing prior to shipment, it delivers consistent quality for volume manufacturing while meeting the rigors of modern electronic systems. Below is a detailed breakdown of its specifications, capabilities, and applications.

PCB Construction Details

The Rogers 3203’s construction is optimized for high-frequency integrity and manufacturability, with key parameters outlined in the table below:

PCB Stackup

As a 2-layer rigid PCB, the Rogers RO3203 PCB features a streamlined stackup that maximizes signal integrity and thermal performance, with layer specifications below:

PCB Statistics

The following metrics reflect the RO3203 high frequency PCB’s optimized layout for efficient assembly, connectivity, and signal transmission:

Core Material & Performance Advantages

At the heart of the RO3203 lies Rogers , a high-frequency laminate engineered to deliver exceptional performance. With a dielectric constant of 3.02±0.04 (10 GHz/23°C) and a dissipation factor of just 0.0016, it extends reliable operation beyond 40 GHz—ideal for applications requiring low signal loss. The woven fiberglass reinforcement enhances rigidity for easier handling during assembly, while its low in-plane CTE (13 ppm/°C for X/Y axes) matches copper, enabling compatibility with epoxy multi-layer hybrid designs and ensuring reliable surface-mounted assemblies.

Key performance features include a thermal conductivity of 0.87 W/mK, Td > 500°C, and 94V-0 flammability, making it suitable for harsh operating environments. The material’s surface smoothness supports finer line etching tolerances, while uniform electrical and mechanical performance ensures high production yields—critical for cost-effective volume manufacturing.

Typical Applications

The Rogers 3203 PCB Board is versatile enough to power next-gen technologies across industries:

- Automotive collision avoidance systems

- Automotive global positions satellite antennas

- Wireless telecommunications systems

- Microstrip patch antennas for wireless communications

- Direct broadcast satellites

- Datalink on cable systems

- Remote meter readers

- Power backplanes

- LMDS and wireless broadband

- Base station infrastructure

Global Availability & Compliance

Supplied with Gerber RS-274-X artwork, the Microwave Rogers 3203 PCB adheres to IPC-Class-2 standards, ensuring compatibility with global manufacturing processes. It is available worldwide, offering a cost-effective solution for high-frequency applications without compromising on performance or reliability.

Whether you’re designing automotive safety systems, wireless infrastructure, or IoT devices, the RO3203 10mil Rogers substrate PCB delivers the precision, stability, and value your project demands. For customizations or volume pricing inquiries, contact our sales team today.
