RO3203 PCB 4-layer 0.6mm Thick Rogers 3203 High Frequency Circuit Material with Immersion Gold

RO3203 PCB 4-layer 0.6mm Thick Rogers 3203High Frequency Circuit Material with Immersion Gold

Introduction

The RO3203 High Frequency Circuit Material, a ceramic-filled laminate reinforced with woven fiberglass, has emerged as a game-changer in the world of PCBs. Engineered with meticulous precision, this cutting-edge product offers exceptional electrical performance and unmatched mechanical stability at a competitive price point. As an extension of the highly acclaimedRO3000 Series, the Microwave Rogers 3203 PCB sets itself apart with its improved mechanical robustness. With a dielectric constant of 3.02 and a dissipation factor of 0.0016, this PCB material extends the useful frequency range beyond an astounding 40 GHz.

Features

2.1 Rogers RO3203 Ceramic-Filled PTFE Composites

TheRO3203 PCB leverages the exceptional qualities of Rogers RO3203 ceramic-filled PTFE composites. These composites enable enhanced electrical performance and outstanding mechanical stability, delivering unrivaled reliability in demanding applications.

2.2 Impressive Electrical Performance

With a dielectric constant of 3.02±0.04 at 10 GHz and a dissipation factor of 0.0016 at 10 GHz, theRogers RO3203 PCB ensures uniform electrical performance across a wide frequency spectrum. Its extraordinary dielectric properties make it ideal for high-frequency applications exceeding 20 GHz.

2.3 High Thermal Performance

The Rogers 3203 PCB Board demonstrates remarkable thermal conductivity, boasting a thermal conductivity value of 0.87 W/mK. With superior heat dissipation capabilities, it ensures optimum thermal management, enabling safe and efficient operation in challenging environments. Furthermore, its Td value exceeding 500°C makes it well-suited for high-temperature applications.

2.4 Thermally Stable and Mechanically Reliable

Designed to withstand extreme conditions, the RO3203 PCB exhibits exceptional dimensional stability and mechanical rigidity. The woven glass reinforcement enhances its robustness, facilitating easier handling and reducing the risk of damage during assembly or operation. Its low in-plane expansion coefficient, closely matched to copper, makes it compatible with epoxy multi-layer board hybrid designs, enabling reliable surface-mounted assemblies.

2.5 Ease of Manufacturing and Cost-Effectiveness

The RO3203 PCB's excellent dimensional stability and uniform properties result in high production yields, making it highly desirable for volume manufacturing. Additionally, its economical pricing ensures cost-effective production, making it an ideal choice for budget-sensitive projects without compromising quality.

2.6 Superior Surface Smoothness

The RO3203 PCB boasts an impeccably smooth surface finish, allowing for finer line etching tolerances. This exceptional characteristic ensures precise trace routing, enabling the realization of intricate and high-density circuit designs.

PCB Stackup and Construction Details

The RO3203 PCB is a 4 layer PCB with a carefully crafted stackup and construction, meticulously engineered to meet the most demanding requirements. The stackup is as follows:

Copper Layer 1: 35μm

Rogers RO3203 Substrate: 10mil (0.254mm)

Copper Layer 2: 35μm

Prepreg FR-28

Copper Layer 1: 35μm

Rogers RO3203 Substrate: 10mil (0.254mm)

Copper Layer 2: 35μm

Performance Specifications

PCB Statistics

Artwork Supplied

The Rogers 3203 PCB accepts Gerber RS-274-X artwork, a widely used industry standard format, ensuring compatibility with various design tools and minimizing potential issues during the manufacturing process.

Accepted Standard: IPC-Class-2

Adhering to industry-recognized standards, the RO320 high frequency PCB complies with the IPC-Class-2 standard, which guarantees high-quality manufacturing processes and consistent product performance.

Availability and Applications

The RO3203 multilayer printed circuit board is available for global distribution, making it accessible to customers worldwide. This versatile circuit material finds numerous applications across various industries, including:

- Automotive collision avoidance systems

- Automotive global positions satellite antennas

- Wireless telecommunications systems

- Microstrip patch antennas for wireless communications

- Direct broadcast satellites

- Datalink on cable systems

- Remote meter readers

- Power backplanes

- LMDS and wireless broadband

- Base station infrastructure

Conclusion
