RO4350B PCB 2-layer Rogers 4350B 16.6mil ENEPIG 35μm Copper Green Solder Mask
Introduction
The RO4350B 2-layer PCB is a high-frequency, high-reliability circuit board designed for demanding RF and microwave applications. Featuring Electroless Nickel Electroless Palladium Immersion Gold (ENEPIG) surface finish, this Rogers PCB ensures excellent solderability, wire bondability, and corrosion resistance. The board is constructed usingRogers RO4350B laminate, a high-performance hydrocarbon/ceramic material that combines the electrical properties of PTFE with the manufacturability of epoxy/glass.
This RO4350B Frequency PCB is ideal for applications requiring low signal loss, stable dielectric constant, and superior thermal performance, making it suitable for cellular base stations, automotive radar, RF identification tags, and satellite communications.
PCB Construction Details
|
Parameter |
Specification |
|
Base Material |
Rogers RO4350B |
|
Layer Count |
2 (Double-sided) |
|
Board Dimensions |
42.3 mm × 30.8 mm (±0.15mm) |
|
Minimum Trace/Space |
4/5 mils |
|
Minimum Hole Size |
0.3mm |
|
Blind Vias |
No |
|
Finished Board Thickness |
0.5mm |
|
Finished Cu Weight |
1oz (35μm) outer layers |
|
Via Plating Thickness |
20μm |
|
Surface Finish |
ENEPIG (Electroless Ni/Pd/Immersion Au) |
|
Top Silkscreen |
No |
|
Bottom Silkscreen |
No |
|
Top Solder Mask |
Green |
|
Bottom Solder Mask |
No |
|
Electrical Testing |
100% tested prior to shipment |
PCB Stackup (2-Layer Rigid PCB)
The stackup is optimized for high-frequency signal integrity with a 16.6 mil RO4350B material and 1oz copper layers.
|
Layer |
Material/Thickness |
|
Copper Layer 1 |
35μm (1oz) |
|
Core |
Rogers RO4350B (0.422mm / 16.6mil) |
|
Copper Layer 2 |
35μm (1oz) |
PCB Statistics
This Rogers 4350B PCB is designed with 8 components, 10 pads, and 5 vias, supporting 2 nets for efficient signal routing.
|
Parameter |
Count |
|
Components |
8 |
|
Total Pads |
10 |
|
Thru-Hole Pads |
6 |
|
Top SMT Pads |
4 |
|
Bottom SMT Pads |
0 |
|
Vias |
5 |
|
Nets |
2 |
Key Features of RO4350B Material
Rogers RO4350B is a high-frequency laminate that provides exceptional electrical and thermal performance while maintaining cost-effective manufacturability.
Electrical & Thermal Properties
CTE (Coefficient of Thermal Expansion):
Glass Transition Temperature (Tg): >280°C
Low Water Absorption: 0.06%
UL 94 V-0 Flame Rated
Benefits of RO4350B PCB
✔Ideal for Multi-Layer Boards (MLB)–Excellent dimensional stability for complex RF designs.
✔Cost-Effective Processing–Compatible with standard FR-4 fabrication techniques.
✔Superior Signal Integrity–Low loss and stable Dk for high-frequency applications.
✔Reliable Plated Through-Holes (PTHs)–Low Z-axis CTE ensures durability under thermal stress.
Applications
This RO4350B high frequency PCB is optimized for high-frequency and high-power RF applications, including:
Quality & Compliance
Conclusion
Our RO4350B 2-layer PCB with ENEPIG finish is a high-performance, reliable solution for RF and microwave applications. With tight impedance control, low loss, and excellent thermal stability, this board is ideal for mission-critical communications, automotive radar, and aerospace systems.
For custom requirements or bulk orders, contact our sales team for further assistance.
