In the era of rapid technological advancement in telecommunications, automotive electronics, and satellite communication, the demand for high-frequency, low-loss printed circuit boards (PCBs) has never been more critical. The WL-CT350 2-Layer 40mil PCB stands out as a premium solution engineered to meet the rigorous requirements of high-frequency designs, combining exceptional material properties, precise manufacturing, and versatile applicability. Crafted with Wangling’s proprietary WL-CT350 high-frequency laminates, this Wangling PCB delivers superior signal integrity, thermal stability, and reliability, making it an ideal choice for industries where performance and consistency are non-negotiable. Below is a comprehensive overview of its specifications, features, and value proposition.

PCB Construction Details

The WL-CT350 2-Layer PCB features precise construction parameters optimized for high-frequency performance and manufacturability, with strict quality control measures including 100% electrical testing prior to shipment.

PCB Stackup

The stackup of the WL-CT350 40 mil PCB is designed to maximize signal integrity and thermal performance, with a symmetric structure that ensures uniform heat distribution and minimal stress.

PCB Statistics

The following statistics reflect the Wangling WL-CT350 PCB’s design complexity and component compatibility, highlighting its suitability for compact, high-performance electronic assemblies.

Core Material: WL-CT350 High-Frequency Laminate

At the heart of the WL-CT350 PCB is Wangling’s WL-CT350 organic polymer ceramic fiberglass cloth-coveredcopper clad laminate—a thermosetting resin-based material tailored for high-frequency applications. Composed of hydrocarbon resin, ceramics, and fiberglass cloth, this laminate offers a compelling alternative to foreign counterparts and traditional materials like PTFE. Unlike PTFE, which requires complex processing, the WL-CT350 material can be processed using techniques similar to standard FR4, simplifying manufacturing while ensuring superior circuitry stability and consistency.

The unique blend of hydrocarbon resin and composite ceramics endows the material with a suite of high-performance characteristics: low loss, exceptional high-temperature resistance, and outstanding temperature stability. With a glass transition temperature (TG) exceeding 280°C, a stable dielectric constant (Dk) and loss temperature coefficient, and a low thermal expansion coefficient, the WL-CT350 laminate ensures reliable operation even in harsh environmental conditions. These properties make the WL-CT350 PCB particularly well-suited for high-frequency designs where signal degradation and thermal stress are major concerns.

(Note: Printed Circuit Boards are custom-made products. Images and parameters are for reference only.)

Key Electrical & Physical Features

The WL-CT350 PCB’s performance is defined by its exceptional electrical and physical properties, which are critical for high-frequency applications:

1) Dielectric Constant (Dk): 3.48 at 10 GHz/23°C, ensuring stable signal propagation in high-frequency circuits.

2) Dissipation Factor (Df): 0.0039 at 10 GHz, minimizing signal loss and ensuring efficient power transmission.

3) Temperature Coefficient of Dielectric Constant (TCDK): 52 ppm/°C, maintaining signal integrity across a wide temperature range.

4) Thermal Conductivity: 0.7 W/MK, enabling effective heat dissipation and preventing thermal buildup in high-power applications.

5) Moisture Absorption: 0.05%, reducing the risk of performance degradation due to environmental moisture.

6) Coefficient of Thermal Expansion (CTE): Matched to copper with 11 ppm/°C (X-axis), 14 ppm/°C (Y-axis), and 34 ppm/°C (Z-axis), minimizing thermal stress and improving long-term reliability.

Typical Applications

This WL-CT350 DK3.48 PCB is perfectly suited for a wide array of high-frequency and high-reliability systems, including but not limited to:

- Base station antennas and satellite antennas.

- Automotive radar, sensors, and navigation systems.

- Power amplifiers.

- Satellite high-frequency heads.

- RF devices and filters.

- WIMAX antennas and distributed antennas.

Supply & Quality Standards

To ensure compatibility with global manufacturing processes and quality requirements, the WL-CT350 PCB adheres to the following standards and supply specifications:

Artwork Format: Gerber RS-274-X (industry-standard format for PCB manufacturing).

Quality Standard: IPC-Class-2, ensuring high reliability for commercial and industrial applications.

Availability: Worldwide, with global supply chain support to meet diverse customer needs.

Conclusion

The WL-CT350 2-Layer 40mil PCB represents a perfect synergy of advanced material technology and precision manufacturing. Its proprietary WL-CT350 laminate delivers superior high-frequency performance, while its optimized construction and strict quality control ensure reliability and consistency. Whether for telecommunications, automotive, or RF applications, this PCB provides engineers with a cost-effective, high-performance solution that meets the demands of today’s most challenging electronic designs. With worldwide availability and compliance with global standards, the WL-CT350 high frequency PCB is poised to become a trusted choice for manufacturers seeking to elevate their product performance.
