RO3010 PCB Rogers 3010 2-layer 20mil 0.254mm Immersion Silver Green Solder Mask White Legend

RO3010 PCB Rogers 30102-layer 20mil 0.254mm Immersion Silver Green Solder Mask White Legend

In the realm of printed circuit boards, precision, durability, and performance are paramount. As we delve into the innovative world of the Rogers RO3010 PCB 20 mil Immersion Silver, a multitude of features and benefits come to light, ensuring that your electronic applications are met with unparalleled quality and reliability. Let us embark on a comprehensive journey through the intricate details and advantages that this cutting-edge PCB offers.

RO3010 PCB Construction

Crafted with meticulous attention to detail, the RO3010 20 mil substrate PCB boasts a sophisticated construction tailored to meet the demands of modern electronic design:

PCB Stackup

The internal architecture of the Rogers 3010 PCB is a testament to its engineering excellence, featuring aDural Layer PCB stackup:

PCB Statistics

The RO3010 High Frequency PCB stands tall with a suite of impressive statistics that set it apart in the realm of electronic design:

RO3010: An Introduction

Rogers RO3010 circuit materials herald a new era of innovation with their ceramic-filled PTFE composites, setting new standards in dielectric performance and stability. These materials are meticulously crafted to simplify broadband component design and can seamlessly adapt to a wide array of frequencies, making them ideal for diverse applications requiring broad frequency coverage.

Features of RO3010

The RO3010 20mil Rogers PCB boasts an array of features that elevate its performance to unparalleled heights:

• Dielectric Constant: An impressive 10.2+/- 0.30 at 10 GHz/23°C for consistent signal integrity.
• Dissipation Factor: Merely 0.0022 at 10 GHz/23°C, ensuring minimal signal loss.
• Coefficient of Thermal Expansion: With values of 13 ppm/°C (X), 11 ppm/°C (Y), 16 ppm/°C (Z), ensuring dimensional stability across a wide temperature range.
• Thermal Conductivity: A notable 0.95 W/mK for efficient heat dissipation.
• Moisture Absorption: A minimal 0.05%, safeguarding against environmental factors.
• Operating Temperature Range: From -40°C to +85°C, making it versatile for various operating conditions.

Benefits

The Rogers 3010 PCB doesn't just stop at features—it offers a host of benefits that make it a game-changer in the electronics industry:

• -Dimensional Stability: Matches expansion coefficient with copper for enhanced performance.
• -Economical Pricing: Optimal laminate pricing for volume manufacturing processes, ensuring cost efficiency.
• -ISO 9001 Certification: A mark of quality assurance that guarantees adherence to stringent standards.
• -Multi-layer Compatibility: Ideal for use in multi-layer board designs, offering versatility in complex applications.

Applications

The versatility of the RO3010 20 mil substrate PCB shines through in a myriad of applications, including:

- Automotive radar applications

- Global positioning satellite antennas

- Cellular telecommunications systems - power amplifiers and antennas

- Patch antenna for wireless communications

- Direct broadcast satellites

- Datalink on cable systems

- Remote meter readers

- Power backplanes

Conclusion

In conclusion, the RO3010 PCB 20 mil Immersion Silver stands as a pinnacle of PCB excellence, blending cutting-edge technology with unparalleled performance. From its advanced construction and superior features to its diverse applications and benefits, this Rogers PCB redefines the standards of quality and reliability in the realm of circuit materials. Embrace the future of electronics with the RO3010 PCB and elevate your designs to new heights of innovation and excellence.
